Item | Specification | BS-2030M | BS-2030B | BS-2030T | BS-2030BD |
Viewing Head | Monocular Head Inclined at 45°, 360° Rotatable | ● | |||
Sliding Binocular Head Inclined at 45°, 360° Rotatable; interpupillary distance 55-75mm. | ● | ||||
Sliding Trinocular Head, inclined at 45 º and 360 º Rotatable, interpupillary distance 55-75mm | ● | ||||
Seidentopf Binocular Head Inclined at 45°, 360° Rotatable,interpupillary distance 48-75mm. | ○ | ||||
Sliding Binocular Head with 1.3MP digital camera, Inclined at 45°, 360° Rotatable; interpupillary distance 55-75mm. | ● | ||||
Anti-mould. | ○ | ○ | ○ | ○ | |
Eyepiece | Wide Field Eyepiece WF10×/ 18 | ● | ● | ● | ● |
Wide Field Eyepiece WF16×/ 11 | ○ | ○ | ○ | ○ | |
Nosepiece | Quadruple Nosepiece | ● | ● | ● | ● |
Quintuple Nosepiece | ○ | ○ | ○ | ○ | |
Objective | Achromatic Objective 4×, 10×, 40×, 100× | ● | ● | ● | ● |
Achromatic Objective 20×, 60× | ○ | ○ | ○ | ○ | |
Plan Achromatic Objective 4×, 10×, 20×, 40×, 60×, 100× | ○ | ○ | ○ | ○ | |
Total magnifications | With 10x eyepiece: 40×, 100×, 400×, 1000× | ● | ● | ● | ● |
With 16x eyepiece: 64×, 160×, 640×, 1600× | ○ | ○ | ○ | ○ | |
Stage | Double Layer Mechanical Stage 140×140mm/ 75×50mm | ● | ● | ● | ● |
Focus | Coaxial Coarse & Fine Adjustment, Fine Division 0.002mm, Coarse Stroke 37.7mm per Rotation, FinStroke 0.2mm er Rotation Movin Rane 28mm | ● | ● | ● | ● |
Condenser | Abbe NA 1.25 with Iris Diaphragm & Filter | ● | ● | ● | ● |
Illumination | LED Illumination, Brightness Adjustable | ● | ● | ● | ● |
6V/20W Halogen light, Brightness Adjustable | ○ | ○ | ○ | ○ | |
Plan-concave Mirror | ● | ● | ● | ● | |
Body / Energy | Firm Aluminum Body and built in power supply 110-240V | ● | ● | ● | ● |
Supplied with | Dust cover, blue&green filter, immersion oil and user manual | ● | ● | ● | ● |
Polarization Set | Simple Polarization Set | ○ | ○ | ○ | ○ |
Phase Contrast Kit | Simple phase contrast kit | ○ | ○ | ○ | ○ |
Sliding phase contrast kit | ○ | ○ | ○ | ○ | |
Turret phase contrast kit | ○ | ○ | ○ | ○ | |
Dark Field Attachment | Dark Field Attachment (Dry) NA0.9 | ○ | ○ | ○ | ○ |
Dark Field Attachment (Oil) NA1.25-1.36 | ○ | ○ | ○ | ○ | |
Fluorescent Attachment | YX-2B Fluorescent Attachment | ○ | ○ | ○ | ○ |
Battery | Rechargeable battery(only for LED illumination) | ○ | ○ | ○ | ○ |
Package | 1pc/carton, 33cm×28cm×44cm×, 7kg | ● | ● | ● | ● |
