Product Name: | Oral Therapy Equipments & Accessories | Brand Name: | Zhoek |
Model Number: | DOM-800 | Warranty: | 1 year |
After-sale Service: | Online Technical Support | Illumination: | LED |
magnification: | 0.4X-2.4X(1:6) | Eyepiece: | Wide Field WF12.5X/18B（10 X/18B） |
binocular tube: | 0-220 degree | Usage: | Dentist Working Partner |
Model | DOM800 | ||||||
Function | Dental | ||||||
Electrical data | |||||||
Power socket | 220v(+10%/-15%) 50HZ/110V(+10%/-15%) 60HZ | ||||||
Power consumption | 40VA | ||||||
Safety class | class I | ||||||
Microscope | |||||||
Binoculars | 0-220 binocular tube | ||||||
Magnification | 0.4X-2.4X(1:6) , total magnification 3.6X-21.6X ( F 250mm) | ||||||
Objectives | F=200mm-450mm | ||||||
Objective focusing | 250mm | ||||||
Eyepiece | 12.5x/ 18B(10x/18B for optional) | ||||||
diopter adjustment | +6D ~ -6D | ||||||
Feild of veiw | 9.3mm-55.6mm | ||||||
Illumination | |||||||
Light source | LED cold light,illumination diameter of light spot Φ50mm with life time >100000 hours, brightness >50000 lux CRI>90 | ||||||
Banlance arm | 120° Banlance arm | ||||||
Filter | build-in standard spot, green filter, yellow filter. | ||||||
Power supply | AC 110V/220V - 220W | ||||||
Stands | |||||||
Max extension range | 1428mm | ||||||
Base | 640mm × 640mm | ||||||
Rotation angle | 270 degree | ||||||
Movable floor stand frame | Including base, column, big cross arm(340mm),small cross arm(650mm) and so on. height:1800mm, The range of up-down≥350mm | ||||||
Brake system | Fine adjustable mechanical brakes for all rotation axes with detachable brake | ||||||
System weight | 110kg | ||||||
Stand options | Ceiling mount,Wall mount,Floor stand,Floor plate | ||||||
